TM 236 Drum Brake Apparatus

Laboratory:
Vibrations and Mechanics of Machines Laboratory
Brake drum apparatus and its description
Trailing brake
Leading brake



 The Figures (2 & 3) show the two types of brake drum trailing brake and leading brake.


 They consist of:

1.       Braking force

2.       Peripheral force

3.       The drum

4.       Drive cable

5.       Deflection pulley
